M18 ultrasonic sensor

Article number Info DimensionPolarity and OutputConnectionOperating range
pico+25/F/A Ultraljudsgivare M18 med hus i förnicklad mässing M18x53mm Push-Pull

M12, 5-pol 30-250mm max 350mm
UK1C/G2-0ESY Ultrasonic sensor with sensor housing in impact-resistant plastic. Adjustment with teach-in button. M18x92mm 4-20mA M12, 5-pol 100-900mm
pico+25/WK/F/A Ultrasonic sensor M18 with housing in nickel-plated brass in angled design. M18x69mm Push-Pull

M12, 5-pol 30-250mm max 350mm
UK6A/HP-0EUL Ultrasonic sensor with a short sensor housing in impact-resistant plastic. Adjustment with teach-by-wire. M18x60mm PNP NO/NC M12, 4-pol 40-300mm
UK6A/HP-1EULAN Ultrasonic sensor with a short sensor housing in acid-resistant steel. Adjustment with teach-by-wire. ATEX classified for zone 2 & 22. M18x60mm PNP NO/NC M12, 4-pol 40-300mm
UK6C/HP-1EULAN Ultrasonic sensor with a short sensor housing in acid-resistant steel. Adjustment with teach-by-wire. ATEX classified for zone 2 & 22. M18x60mm PNP NO/NC M12, 4-pol 60-800mm
pico+100/F/A Ultrasonic sensor M18 with housing in nickel-plated brass in angled design. M18x69mm Push-Pull

M12, 5-pol 120-1000mm max 1300mm
pico+35/F/A Ultrasonic sensor M18 with housing in nickel-plated brass in angled design. M18x53mm Push-Pull

M12, 5-pol 65-350mm max 600mm
pico+35/I Ultrasonic sensor M18 with housing in nickel-plated brass in angled design. M18x53mm 4-20mA M12, 5-pol 65-350mm max 600mm
UK6A/H2-1EULAN Ultrasonic sensor with a short sensor housing in acid-resistant steel. Adjustment with teach-by-wire. ATEX classified for zone 2 & 22. M18x60mm 4-20mA M12, 4-pol 60-800mm
UK6C/H2-0EUL Ultrasonic sensor with a short sensor housing in impact-resistant plastic. Adjustment with teach-by-wire. M18x60mm 4-20mA M12, 4-pol 60-800mm
pico+100/I M18 ultrasonic sensor with long range. M18x53mm 4-20mA M12, 5-pol 120-1000mm max 1300mm
UK6D/H2-1EUL Ultrasonic sensor with a short sensor housing in acid-resistant steel. Adjustment with teach-by-wire. M18x60mm 4-20mA M12, 3-pol 80-1200mm
UK6D/HP-1EIO Ultrasonic sensor with sensor housing in acid-resistant steel. Adjustment with teach-by-wire. M18x60mm

M12, 4-pol 80-1200mm
UK1F/G2-0ESYAN ATEX classified ultrasonic sensor for zone 2 & 22. Very long sensing distance. M18x92mm 4-20mA M12, 5-pol 200-2200mm
